​​Features:

• Siemens Touch Screen PLC;
• Grinding wheel motor 15 kW (20 HP), 400-3-50 Hz;
• Grinding wheel Ø250mm (segment grinding wheeel);
• Reversal of grinding wheel rotation;
• Electro-permanent magnetic table 2100x150mm;
• Angular divisor for magnetic table rotation ±90°;
• Controls for rapid grinding wheel descent and ascent and slow descent;
• Motorized automatic grinding wheel descent controlled by Siemens PLC (0.001-0.1 mm);
• Automatic work cycle (roughing, finishing, spark-out);
• Variable carriage speed from 1 to 30 m/min;
• Automatic lubrication of PTFE sliding blocks;
• Coolant through the centre of the grinding wheel + 2 nozzles either side;
• External tank with pump;
• Magnetic cleaner;
• Motorized rapid grinding wheel change;
• Variable grinding wheel speed.
• Automatic approach to work-piece (HSS)
• LED lamp

​Features:

• Grinding motor power 1,5 kW;
• Grinding wheel diameter Ø127mm;
• Maximum external diameter of blade Ø300mm;
• Variable working speed 3-35 rpm;
• Stand;
• Equipment for counter-knives.

​Features:

• Robust cast-iron main machine housing;
• All gears housed in an oil bath (10 kg);
• Band saw blade up to 80mm wide
• Sensitive controls for high precision adjustment;
• Speed regulator;
• Cooling system;
• CBN grinding wheel.

​​Features:

• CNC grinding machine for metalcutting circular saw blades
• HSS circular saw blade diameter: 150 - 650 mm
• Friction circular saw blade diameter: 150 - 710 mm
• Teeth number: 10 - 998
• Maximum saw blade thickness: 6 mm
• Grinding wheel diameter: 150 mm
• Working speed: 2 - 60 teeth/min
• Coolant system motor pump: 50 litres/min - 7.5 bar
• Grinding wheel motor power: 2.2 kW

​Features:

• Automatic chip breaker slot grinding machine
• Circular saw blade diameter: 140 - 630 mm
• Maximum tooth pitch: 35 mm
• Maximum saw blade thickness: 8 mm
• Maximum grinding wheel diameter: 30 mm
• Maximum grinding wheel thickness: 0.6 mm
• Working speed: 40 teeth/min
• Grinding wheel speed: 0 - 50000 rpm
• Air pressure: 6 bar
• Air consumption: 20 litres/min
• Installed power: 0.7 kVA

​Features:

• ​Warranty 6 months;
• Year of production 2006;
• Grinding wheel motor 3,7 kW (5 HP) 400 Volt, threephase, 50 Hz
• Cup wheel Ø150mm;
• Manual downfeed;
• Manual Transversal carriage translation;
• Suitable for double bevel blades;
• Ideal for paper knives and veneer blades;
• Ideal for the KX 250 model grinding machine.

​• Cabin for full working area enclosure

• Two grinding heads for grinding bilateral bevel knives at once, or unilateral bevel knives

• Grinding with emulsion coolant or neat oil

• Control board equipped with panel PC with 10” (16:9) touch screen display, and USB port for connection of mouse, keyboard, Wi-Fi adapter, flash drive

• Easy adjustment for bevel angle

• Lateral fine adjustment of the knife position for centering of the cutting edge

• Quick assembly of circular knife

• Joystick for manual displacement of the grinding slide, with potentiometer for speed adjustment

• Ball rail guide of slides for increased accuracy and durability

• Circular knife spindle with rotation speed digitally programmed and controlled

• Centralized lubrication with manual pump

• LED lamp for grinding area lighting

• Interchangeable shaft, ISO 30 taper, to accommodate a suitable knife clamping system

• Versatility, efficiency, and easy to operate

• Low and simple maintenance

​Features:

• Hydraulic rectifier for blades;
• Automatic movement of the blade;
• Maximum thrust straightening;
• Manometer for pressure straightening control;
• Available with 2 rollers (for blades up to 1500mm) or 4 rollers (2500mm).

​Features:

• Grinding motor 3.7 kW (5 HP);
• Grinding wheel Ø150mm;
• Automatic grinding wheel downfeed;
• Rotating head range 0°-90°;
• Magnetic chuck Ø300mm;
• Variable speed of magnetic chuck 3-35 rpm;
• Coolant pump.

​Features:

• 5.5 kW (7.5 HP) grinding motor;
• Segment grinding wheel Ø178 mm;
• Electro-magnetic chuck 1500x120mm with lever for rotation from 0° to 90°;
• Variable carriage speed 1-20 m/min;
• Switches for carriage stroke reduction;
• PLC (digital programmer);
• Automatic work cycle with adjustment of the partial downfeed and automatic stop at a pre-set quota;
• Spark-out at the end of the working cycle with automatic stopping of the carriage at the right side of the machine base;
• Reverse direction of rotation of the grinding wheel;
• Magnetic cleaner with rotating discs.

​Features:

• Grinding motor 2,2 kW (3HP);
• Ø150mm cup grinding wheel;
• Magnetic chuck 1000x117mm, 0-90° rotating;
• Automatic grinding wheel downfeed and automatic working cycle with mini PLC;
• Variable carriage speed 1-20 m/min;
• External tank with coolant pump.

​

• ​6-month warranty on mechanical parts;
• Year of production 2002;
• Grinding wheel motor 5.5 kW (7,5 HP) 400 Volt, three-phase, 50 Hz;
• Automatic motorised grinding wheel descent and work cycle;
• Grinding wheel Ø178mm (segment wheel);
• Magnetic plane 1000x120 mm with lever for rotating the magnetic plane from 0° to 90°;
• Variable carriage speed 1-20 m / min;
• External tank with pump.

• grinding wheel motor kW 1.8 (HP 2.5)

• rotating magnetic table Ø300mm

• table rotation variable speed 3/35 rpm

• movable column max passage 340 mm

• X and Z working axes on linear guides with 220mm stroke

• Siemens touch screen PLC

• water tank and internal coolant pump

• rotary head with variable angle from 0° to 90°

• automatic working cycle with partial and total descent programming

• electronic handwheel for precision movements

• grinding wheel rotation reversal

​​• Electric fan 0.75 HP

• Compressed air consumption 780 l/min (6 bar)

• Electrical power supply 380 volts 50 Hz

• Useful cabin dimensions 800x600x700mm

• Overall dimensions 1100x1100x1750mm

• Weight 170 kg

​- Year of manufacture 2015

- Maximum pressure 10 bar

- Voltage 400 volts three-phase 50 Hz

- Power 4 kW

​- Automatic machine for removing burr from industrial blades and knives up to 3000mm in length;

- Orbital deburring machines supplied with abrasive cloth paper, 1000 grit;

- No.3 perfectly linear blade rests, with relative clamping, which have the ability to be moved along the linear guide;

- Blade presence sensor for carriage reversal;

- Linear guide with limit switch micro.

​- Maximum pressure 10 bar

- Voltage 400 volts three-phase 50 Hz

- Power 1.5 kW
